Easily extract audio from your HDMI source with this HDMI Audio Extractor, designed to send high-quality sound to external audio systems via SPDIF Optical and RCA outputs. Enjoy simultaneous audio output through both ports when the input is set to stereo.

This device supports HDMI ARC (Audio Return Channel), allowing you to extract audio from your TV through the SPDIF Optical port. (Note: ARC supports Optical output only; eARC not supported.)

Experience sharp visuals with full support for 4K@60Hz, 1080P@120Hz, and 1080P@144Hz resolutions, along with HDR 10-bit color for enhanced picture quality. Fine-tune your setup using three selectable Audio EDID modes, ensuring the correct format for your sound system.

Perfect for home theaters, soundbars, and AV receivers, this extractor delivers reliable, high-definition audio and video performance.

✅ HDMI 2.0b (18Gbps), HDCP 2.2, and DVI compliant.

✅ Supports video resolutions up to 4K2K@50/60Hz (YUV444).

✅ Extracts HDMI audio to multi-channel optical (SPDIF) or L/R analog audio.

✅ Optical audio supports LPCM 2CH, Dolby Digital 2/5.1CH, and DTS 2/5.1CH.

✅ Supports HDMI High Bit Rate (HBR) audio pass-through.

✅ Audio sample rates up to 192kHz.

✅ 10-bit HDR (High Dynamic Range) pass-through.

✅ Supports ARC and CEC bypass.

*Please Note: If you are not able to get audio from either Optical or 3.5mm output ports, please check your input source audio settings and ensure that the audio output is set to either PCM (For 3.5mm output), or PCM, DTS, or Dolby Digital (For Optical output). If the input source device is outputting Dolby Digital+ (DD+) or higher audio format, the extractor will not pass audio through the audio output ports.
